• Full moldboard trip with four (4) extension type springs
  • 11′ plow length / 33″ inlet, 58″ outlet plow heights (measured w/6″ cutting blade)
  • 12′ plow length / 33″ inlet, 60″ outlet plow heights (measured w/6″ cutting blade)
  • 3/16″ moldboard
  • Eight (8)″ ribs, fully welded (8 3/8″ counting endplate)
  • Two (2) heavy duty 4″x 19″ reversing cylinders with 2″ nitrated rods
  • Cylinders are mounted above the push frame
  • Push frame is 102″ wide with six (6) main hinge points
  • Push frame constructed with 3/8″x 4″x 4″ square tubing
  • 3/4″x 4″x 4″ lower angle
  • Adjustable attack angles – 10 & 20 degrees
  • 5/8″x 8″ cutting edge with standard AASHO punch
  • Various hitches available, plow & truck portions
  • 10ga. 201 or 304 stainless steel moldboard in lieu of standard
  • DXV Cushion valve to protect reversing cylinders (shipped loose)
  • Rubber snow flap, 3-ply, 1/2″ thick x 12″ wide (installed with carbon steel retainer bar)
  • Rubber snow flap, 3-ply, 1/2″ thick x 18″ wide (installed with carbon steel retainer bar)
  • Stainless Steel retainer bar, bolts, and nuts for rubber flap in lieu of carbon steel
  • Plow end markers, 27″ red cable type (installed)
  • Plow end markers, 36″ orange cable type (installed)
  • Plow end markers, 28″ orange plastic type (installed)
  • Plow end markers, 36″ orange plastic type (installed)
  • Plow end markers, 48″ orange plastic type (installed)
  • Crank adjustable parking stand, (installed)
  • Heavy Duty push frame
  • Shoe brackets only, installed (no shoe assembly included) (need to order shoe assembly separate)
  • Adjustable mushroom shoes with standard pads (installed)
  • Adjustable mushroom shoes with Ni-Hard pads (installed)
  • Adjustable shoes with Flat shoe pad style (installed)
  • Snow Wheel Shoe brackets & Snow Wheel Assembly
  • One Piece Trip Cutting Edge in lieu of moldboard trip (10′ & 11′ plow)
  • One Piece Trip Cutting Edge in lieu of moldboard trip (12′ plow)
  • Three piece trip cutting edge in lieu of moldboard trip (11′ & 12′ plows only)
  • Moldboard Trip/Trip cutting edge combination
  • Individually replaceable trip springs in lieu of standard trip springs (all trip edge plows)
  • 3/4″ x 4″ x 4″ lower trip edge angle ILO std. 1/2″ x 3″ x 4″ (all trip edge plows)
  • Curb shoe (installed)
  • Cutting edge shoe (installed)
  • Carbide cutting blades 3/4″ x 6″
  • 3/4” re-rod welded to each end of the plow
  • Guard rail corner cut
  • Mailbox cut
  • Weld on Customer ID Numbers on the Plow Moldboard (location details are required)
  • 3/16″ moldboard in lieu of standard
  • 10ga. 201 or 304 stainless steel moldboard in lieu of standard
  • 7ga. 201 or 304 stainless steel moldboard in lieu of standard
